• Assist handle, front passenger (Also includes rear outboard passenger assist handle on Extended Cab Models.)
• Cigarette lighter, on instrument panel
• Coat hook, driver side (Also includes passenger side coat hook on Extended Cab Models.)
• Console, overhead mini, includes map lights
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Cupholders, front (Also includes rear cupholders on Extended Cab Models)
• Defogger, rear-window, electric (Deleted when (A28) Window, rear sliding is ordered)
• Door locks, power
• Floor covering, color-keyed carpeting and rubberized vinyl floormats (with Extended Cab, includes rear floormats) (May be substituted with (PDP) Floor covering, Graohite-colored rubberized vinyl)
• Headliner, Shale-colored cloth, with matching retainer moldings
• Keyless entry, remote, includes 2 transmitters, panic button and content theft alarm
• Lighting, dome lamp, reading, courtesy, illuminated entry feature, backlit instrument panel switches and door handle-activated illuminated entry
• Mirror, inside rearview, electrochromic (light-sensitive auto dimming), 8-point compass and outside temperature indicator
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Seat trim, Custom Cloth
• Seats, rear bench, folding, 3-passenger (includes child seat top tether anchor) (Standard with Extended Cab Models only)
• Steering wheel, leather-wrapped rim, Black, steel sleeve, includes theft-deterrent locking feature
• Theft-deterrent system, PASSlock II
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
• Warning tones, headlamp on, key-in-ignition, driver and passenger seat belt reminders, turn signal on
• Windows, power, includes driver express-down

• Alternator, 105 amps (Not standard with (NYS) 4-wheel steering)
• Battery, heavy-duty, 600 cold-cranking amps, includes rundown protection and retained accessory power
• Brakes, 4-wheel antilock, 4-wheel disc
• Exhaust, aluminized stainless-steel muffler and tailpipe
• Frame, ladder-type
• GVWR, 6200 lbs. (2812 kg) (Requires TC15753 Models. - Not available with (NYS) 4-wheel steering.)
• Pickup bed, Wideside box
• Rear axle, 3.42 ratio (Standard on 2WD Models only)
• Rear wheel drive
• Recovery hooks, 2 front, frame-mounted (Recovery hooks required on 1500 models)
• Steering, power
• Suspension Package, Handling/Trailering, heavy-duty
• Suspension, front, independent (2WD Models include coil springs. -4WD Models include torsion bars.)
• Suspension, rear, semi-elliptic 2-stage multi-leaf springs
• Tire carrier, outside spare, winch-type mounted under frame at rear
• Tire, spare, full-size, 16" (40.6 cm) with steel wheel located at rear underbody of vehicle
• Tools, mechanical jack and wheel wrench, spare tire assist hook, floor-mounted in back of cab

• Air bags, frontal, driver and right front passenger, includes Passenger Sensing System (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information.)
• Brakes, 4-wheel antilock, 4-wheel disc
• Daytime running lamps, includes automatic exterior lamp control

ENGINE, VORTEC 5300 V8 SFI ($0)

(295 HP @ 5200 rpm 330 lb.-ft. @ 4000 rpm) -Included with (PDU) Light Duty Power Package)

TRANSMISSION, 4-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED W/OVERDRIVE AND TOW/HAUL MODE ($0)

(STD)

SOUND SYSTEM, ETR AM/FM STEREO WITH CD AND CASSETTE PLAYER ($595)

includes seek-and-scan digital clock auto-tone control speed-compensated volume TheftLock Radio Data System (RDS) and 4-speakers on Regular Cab and 6-speakers on Extended Cab Models (with bucket seats UB1 includes Bose speaker system Bose amplifier and Bose subwoofer)

DIFFERENTIAL, LOCKING, HEAVY-DUTY, REAR ($295)

(Included with (PDL) Off-Road Package or (PDU) Light Duty Power Package.

PICKUP BED, WIDESIDE BOX ($0)

(STD)

SUSPENSION PACKAGE, HANDLING/TRAILERING, HEAVY-DUTY ($0)

(STD)

TRAILERING EQUIPMENT, HEAVY-DUTY ($330)

includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector 7-way to 4-way trailer adapter instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner high capacity and (KNP) Cooling external transmission oil cooler. Included with (PDU) Light Duty Power Package)

TEXAS/OKLAHOMA/LOUISIANA/CALIFORNIA/FLORIDA/ NEW MEXICO SLE PACKAGE ($620)

includes (UB1) Sound system ETR AM/FM stereo with CD and cassette player (K47) Air cleaner high capacity and (**D) Seat trim Custom Cloth

SEATS, FRONT 40/20/40 SPLIT-BENCH, 3-PASSENGER, DRIVER AND PASSENGER MANUAL RECLINING ($1,040)

center fold-down armrest with storage adjustable outboard head restraints and storage pockets on Extended Cabs (STD)

SEAT TRIM, CUSTOM CLOTH ($0)

(STD)

AIR CLEANER, HIGH-CAPACITY ($25)

(Included with (Z71) Suspension Package Off-Road or (Z82) Trailering equipment heavy-duty)

WHEELS, 4-16" X 7" (40.6 CM X 17.8 CM) 6-LUG BRIGHT MACHINED ALUMINUM ($200)

includes steel spare (Included with (PDL) Off-Road Package)

SLE PREFERRED EQUIPMENT GROUP ($0)

includes standard equipment

LIGHT DUTY POWER PACKAGE ($1,675)

includes (LM7) Engine Vortec 5300 V8 SFI or (L59) Engine Vortec 5300 V8 SFI (G80) Differential automatic locking heavy-duty or (G86) Differential limited slip heavy-duty and (Z82) Trailering equipment heavy duty

LICENSE PLATE BRACKET, FRONT ($0)

(will be forced on orders with ship-to states that require a front license plate)

COOLING, EXTERNAL TRANSMISSION OIL COOLER, AUXILIARY, HEAVY-DUTY AIR-TO-OIL ($95)

-Included with (VYU) Snow Plow Prep Package or (Z82) Trailering equipment heavy-duty)

GVWR, 6200 LBS. (2812 kg) ($0)

(STD)

• ENGINE VORTEC 5300 V8 SFI (295 HP @ 5200 rpm 330 lb.-ft. @ 4000 rpm) -Included with (PDU) Light Duty Power Package)
• TRANSMISSION 4-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED W/OVERDRIVE AND TOW/HAUL MODE (STD)
• SOUND SYSTEM ETR AM/FM STEREO WITH CD AND CASSETTE PLAYER includes seek-and-scan digital clock auto-tone control speed-compensated volume TheftLock Radio Data System (RDS) and 4-speakers on Regular Cab and 6-speakers on Extended Cab Models (with bucket seats UB1 includes Bose speaker system Bose amplifier and Bose subwoofer)
• DIFFERENTIAL LOCKING HEAVY-DUTY REAR (Included with (PDL) Off-Road Package or (PDU) Light Duty Power Package.
• PICKUP BED WIDESIDE BOX (STD)
• SUSPENSION PACKAGE HANDLING/TRAILERING HEAVY-DUTY (STD)
• TRAILERING EQUIPMENT HEAVY-DUTY includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector 7-way to 4-way trailer adapter instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner high capacity and (KNP) Cooling external transmission oil cooler. Included with (PDU) Light Duty Power Package)
• TEXAS/OKLAHOMA/LOUISIANA/CALIFORNIA/FLORIDA/ NEW MEXICO SLE PACKAGE includes (UB1) Sound system ETR AM/FM stereo with CD and cassette player (K47) Air cleaner high capacity and (**D) Seat trim Custom Cloth
• SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER DRIVER AND PASSENGER MANUAL RECLINING center fold-down armrest with storage adjustable outboard head restraints and storage pockets on Extended Cabs (STD)
• REAR AXLE 3.73 RATIO
• SEAT TRIM CUSTOM CLOTH (STD)
• AIR CLEANER HIGH-CAPACITY (Included with (Z71) Suspension Package Off-Road or (Z82) Trailering equipment heavy-duty)
• WHEELS 4-16" X 7" (40.6 CM X 17.8 CM) 6-LUG BRIGHT MACHINED ALUMINUM includes steel spare (Included with (PDL) Off-Road Package)
• PAINT TWO-TONE
• SLE PREFERRED EQUIPMENT GROUP includes standard equipment
• LIGHT DUTY POWER PACKAGE includes (LM7) Engine Vortec 5300 V8 SFI or (L59) Engine Vortec 5300 V8 SFI (G80) Differential automatic locking heavy-duty or (G86) Differential limited slip heavy-duty and (Z82) Trailering equipment heavy duty
• LICENSE PLATE BRACKET FRONT (will be forced on orders with ship-to states that require a front license plate)
• COOLING EXTERNAL TRANSMISSION OIL COOLER AUXILIARY HEAVY-DUTY AIR-TO-OIL -Included with (VYU) Snow Plow Prep Package or (Z82) Trailering equipment heavy-duty)
• GVWR 6200 LBS. (2812 kg) (STD)
• TIRES P255/70R16 ALL-SEASON BLACKWALL
• Rear Wheel Drive
• Tow Hooks
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Conventional Spare Tire
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Automatic Headlights
• Daytime Running Lights
• Automatic Headlights
• Fog Lamps
• Heated Mirrors
• Power Mirror(s)
• Privacy Glass
• Intermittent Wipers
• Cloth Seats
• Split Bench Seat
• Rear Bench Seat
• Floor Mats
• Adjustable Steering Wheel
• Leather Steering Wheel
• Immobilizer
• Rear Defrost
• Cruise Control
• Power Door Locks
• Power Windows
• Security System
• Keyless Entry
• Power Door Locks
• Multi-Zone A/C
• A/C
• AM/FM Stereo
• CD Player
• Power Outlet
• Auto-Dimming Rearview Mirror
• Front Reading Lamps
• Passenger Vanity Mirror
• Front Reading Lamps
• ABS
• 4-Wheel Disc Brakes
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag Sensor
• Daytime Running Lights
• Automatic Headlights

• Brakes
• Brake ABS System: Four-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.10
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 0.78
• Cargo Area Dimensions
• Cargo Box (Area) Height (in): 19.5
• Cargo Box Length : Floor (in)
• Cargo Box Width : Floor (in)
• Cargo Box Width : Top, Rear (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume (ft³): 56.9
• Tailgate Width (in): 64.8
• Cooling System
• Total Cooling System Capacity (qts): 13.88
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 105
• Exterior Dimensions
• Cab to Axle (in): 41.9
• Front Bumper to Back of Cab (in): 138.5
• Ground Clearance, Front (in): 8.0
• Ground Clearance, Rear (in): 8.3
• Ground to Top of Load Floor (in): 35.9
• Height, Overall (in): 71.2
• Length, Overall w/o rear bumper (in): 230.2
• Overhang, Front (in): 36.9
• Overhang, Rear w/o bumper (in): 47.3
• Wheelbase (in): 143.5
• Width, Max w/o mirrors (in): 78.5
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: LH
• Interior Dimensions
• Front Head Room (in): 41.0
• Front Hip Room (in): 61.4
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Passenger Capacity: 6
• Second Head Room (in): 38.4
• Second Hip Room (in): 61.5
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 66.3
• Mileage
• EPA Fuel Economy Est - City (MPG): 16
• EPA Fuel Economy Est - Hwy (MPG): 19
• Steering
• Steering Ratio (:1), On Center: 14.2
• Steering Type: Pwr
• Turning Diameter - Curb to Curb (ft): 45.3
• Summary
• Body Code: E63
• Body Style: Ext Cab 6.5' Wideside
• Vehicle Name: GMC Sierra 1500
• Suspension
• Axle Capacity - Front (lbs): 3600
• Axle Capacity - Rear (lbs): 3750
• Axle Ratio (:1) - Rear: 3.73
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Shock Absorber Diameter - Front (mm): 36
• Shock Absorber Diameter - Rear (mm): 36
• Spring Capacity - Front (lbs): 3739
• Spring Capacity - Rear (lbs): 3686
• Stabilizer Bar Diameter - Front (in): 1.42
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Tires
• Front Tire Capacity (lbs): 2064
• Front Tire Order Code: QCC
• Front Tire Size: P255/70R16
• Rear Tire Capacity (lbs): 2064
• Rear Tire Order Code: QCC
• Rear Tire Size: P255/70R16
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Spare Tire Capacity (lbs): 1913
• Spare Tire Order Code: QCC
• Spare Tire Size: P255/70R16
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1215
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 8100
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 810
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 8100
• Weight Information
• Curb Weight - Front (lbs): 2592
• Curb Weight - Rear (lbs): 1834
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 3686
• Gross Combined Wt Rating (lbs): 13000
• Gross Vehicle Weight Rating Cap (lbs): 6200
• Wheels
• Front Wheel Material: Aluminum
• Front Wheel Size (in): 16 x 7
• Rear Wheel Material: Aluminum
• Rear Wheel Size (in): 16 x 7
• Spare Wheel Material: Steel
• Spare Wheel Size (in): 16 x 7
